Helicoil鋼絲螺套公制規格
Helicoil鋼絲螺套是一種由高精度、品質優良的菱形不銹鋼絲精制而成的新型內螺紋緊固件，是一種較好的內螺紋加強、緊固和防松的解決方案，原產于美國，是美國MASA承認的螺紋護套品牌。
Helicoil Inserts是成熟產品，它的使用，大大降低了螺紋的松脫、亂扣、爛牙風險，提高產品性能，減少產品尺寸，延長產品壽命、降低報廢率。Helicoil的使用還可以提高產品附加值，特別對于尖端產品或者行業領先產品。具有不可估量的作用。
Helicoil螺套系統中，Helicoil鋼絲螺套公制規格是應用相對較多的一種規格，下表為詳細規格參數：
METRIC |
||||||
Insert Size |
Drill Size |
Screw Thread Insert Length |
||||
1D |
1.5D |
2D |
2.5D |
3D |
||
M2*0.4 |
2.10 |
2.00 |
3.00 |
4.00 |
5.00 |
6.00 |
M2.2*0.45 |
2.30 |
2.20 |
3.30 |
4.40 |
5.50 |
6.60 |
M2.5*0.45 |
2.60 |
2.50 |
3.75 |
5.00 |
6.25 |
7.50 |
M3*0.5 |
3.10 |
3.00 |
4.50 |
6.00 |
7.50 |
9.00 |
M3.5*0.6 |
3.60 |
3.50 |
5.25 |
7.00 |
8.75 |
10.50 |
M4*0.7 |
4.10 |
4.00 |
6.00 |
8.00 |
10.00 |
12.00 |
M4.5*0.75 |
4.70 |
4.50 |
6.75 |
9.00 |
11.25 |
13.50 |
M5*0.8 |
5.20 |
5.00 |
7.50 |
10.00 |
12.50 |
15.00 |
M6*1.0 |
6.20 |
6.00 |
9.00 |
12.00 |
15.00 |
18.00 |
M7*1.0 |
7.20 |
7.00 |
10.50 |
14.00 |
17.50 |
21.00 |
M8*1.0 |
8.20 |
8.00 |
12.00 |
16.00 |
20.00 |
24.00 |
M8*1.25 |
8.30 |
8.00 |
12.00 |
16.00 |
20.00 |
24.00 |
M9*1.25 |
9.30 |
9.00 |
13.50 |
18.00 |
22.50 |
27.00 |
M10*1.0 |
10.30 |
10.00 |
15.00 |
20.00 |
25.00 |
30.00 |
M10*1.25 |
10.30 |
10.00 |
15.00 |
20.00 |
25.00 |
30.00 |
M10*1.5 |
10.30 |
10.00 |
15.00 |
20.00 |
25.00 |
30.00 |
M11*1.5 |
11.30 |
11.00 |
16.50 |
22.00 |
27.50 |
33.00 |
M12*1.25 |
12.30 |
12.00 |
18.00 |
24.00 |
30.00 |
36.00 |
M12*1.5 |
12.40 |
12.00 |
18.00 |
24.00 |
30.00 |
36.00 |
M12*1.75 |
12.40 |
12.00 |
18.00 |
24.00 |
30.00 |
36.00 |
M14*1.25 |
14.30 |
14.00 |
21.00 |
28.00 |
35.00 |
42.00 |
M14*1.5 |
14.30 |
14.00 |
21.00 |
28.00 |
35.00 |
42.00 |
M14*2.0 |
14.30 |
14.00 |
21.00 |
28.00 |
35.00 |
42.00 |
M16*1.5 |
16.25 |
16.00 |
24.00 |
32.00 |
40.00 |
48.00 |
M16*2.0 |
16.50 |
16.00 |
24.00 |
32.00 |
40.00 |
48.00 |
M18*1.5 |
18.25 |
18.00 |
27.00 |
36.00 |
45.00 |
54.00 |
M18*2.0 |
18.50 |
18.00 |
27.00 |
36.00 |
45.00 |
54.00 |
M18*2.5 |
18.50 |
18.00 |
27.00 |
36.00 |
45.00 |
54.00 |
M20*1.5 |
20.25 |
20.00 |
30.00 |
40.00 |
50.00 |
60.00 |
M20*2.0 |
20.50 |
20.00 |
30.00 |
40.00 |
50.00 |
60.00 |
M20*2.5 |
20.50 |
20.00 |
30.00 |
40.00 |
50.00 |
60.00 |
M22*1.5 |
22.50 |
22.00 |
33.00 |
44.00 |
55.00 |
66.00 |
M22*2.0 |
22.50 |
22.00 |
33.00 |
44.00 |
55.00 |
66.00 |
M22*2.5 |
22.50 |
22.00 |
33.00 |
44.00 |
55.00 |
66.00 |
M24*1.5 |
24.25 |
24.00 |
36.00 |
48.00 |
60.00 |
72.00 |
M24*2.0 |
24.25 |
24.00 |
36.00 |
48.00 |
60.00 |
72.00 |
M24*3.0 |
24.75 |
24.00 |
36.00 |
48.00 |
60.00 |
72.00 |
M27*2.0 |
27.50 |
27.00 |
40.50 |
54.00 |
67.50 |
81.00 |
M27*3.0 |
27.50 |
27.00 |
40.50 |
54.00 |
67.50 |
81.00 |
M30*1.5 |
30.50 |
30.00 |
45.00 |
|||
