French DUBUIS grounding expansion plug screw plug and track screw

Difference between two kinds of plug pin:

Grounding plug nail is used in vehicle equipment use.

Tracks fill nail is used in track back ground and signal transmission.

Introduction:

1, DUBIS grounding plug screw

Earth Bond Hardware

Earth bond for steel and stainless plates

Grounding plug is suitable for stainless steel plate

Earth bond for aluminium plates

Grounding plug is suitable for aluminum plate

Plug pin grounding system is in electrical safety connections between structure and equipment to ensure that the won't appear when the high intensity of current through the wire short circuit of a revolutionary method.

Used in iron and stainless steel plate of the grounding plug pin:

Low tin bronze bushing

Low of 316 l stainless steel bolts

Used for aluminum plate grounding plug pin:

Low aluminum nickel plating bushing

Low of 316 l stainless steel bolts

Grounding nut:

Low and similar, by conducting bushing and the bolt with internal thread

Product features:

Suitable for carbon steel, stainless steel and aluminum plate

Low is suitable for the thickness of 1.5 mm and above board

"Unilateral actions to complete the installation

* can be installed to the blind hole

The electrical connection in the low permanent low resistance

Low in the case of damage to remove and replace

Can be used to not flat surface

Low made from corrosion resistant material

Low cost efficiency is high, because you just need to limited tools repeat installation work

When a single operation

Low independent testing

Low in RMT, Marine and military market major OEM is recommended

2, DUBIS tracks plug screw

DUBIS provides reliable connection solution, use this concept to bottom of the rail network will greatly improve. In railway nail installation, and nail the rail have no impact. As long as no vehicles through which you can use different types of drawing tools installation of various specifications of the plug. Ductility and conductivity best tin copper bush makes signal terminal electrical connection between the best and orbit.

Through the SNCF (the French national railway) certification
